Bestpack AS22-3 Fully Automatic Carton Sealer
The BestPack AS Series is an operator-free carton sealer designed to meet the needs of uniform in-line carton closure applications. Designed with a solid four column support structure and using dual motor side belt technology, the AS closes all four top flaps and seals the top & bottom of the carton, using 45-60 PSI and 4-5 SCFM of air.
Features
- Various tape roll lengths
- Adjustable bed height
- Width/Height Adjustment Knobs
- Upper Side Compression Unit
- Heavy Duty Frame
- Interlock Safety Gates in Kicker Station
- Electrical On/Off Box
- UL Approved Electrical Parts
- Exclusive Pop-Out Pressure Sensitive “High Speed” Tape Head
Applications
| Cartons |
Specifications
| Speed | Up to 57 cartons/min. |
| Power Requirements | 110 Volts; 60 Hz |
| Air Requirements | 45-60 PSI, 4-5 SCFM |
| Shipping Weight | 650-760 lbs. |
| Machine Dimensions | (77.7”) x (33.8”) x (69.0”) |
| Carton Range | (7.5" - 27.5") x (6.0" - 20.0") x (5.5" - 20.0") |
| Conveyor Height and Adjustment | (22.5" - 30.0") |
